on-grid working systemoff-grid working system
ce,iso,ccc approved;
Now we have FD10-10kw model, rated wind speed is 10m/s.
Tower height, tower type, working voltage can be special request.
Below is FD7-10kw normal data:
Model: FD7-10KW
Rotor Diameter: 7m
Number of Blades: 3pcs
Material of Blades: Fibre glass expoxy
Cut-in wind speed: 3m/s
Working wind speed: 4-30m/s
Survival wind speed: 50m/s
Rated wind speed: 12m/s
Rated rotate speed: 260r/min
Rated output power: 10kw
Max output power: 15kw
Type of tower: Manganese steel independence tower, guy wire tower
Type of generator: Permanent-magnet 3 phrase AC
Speed regulation method: Yaw
Stop method: Brake by hand drag
Working voltage: DC500V
Tower height: 10m or special requested;
Wind turbine main body weight: 665kg
Life span: 15 years;
Warranty: 2 years
