Our company designs, develops, produces and markets all kinds of Knuckle Boom Truck-mounted Crane, Telescopic Boom Truck-mounted Crane，Railway Crane and Water Tower Fire Trucks. With the advantages high mobility, easy operation and high operating efficiency, these kinds of Truck cranes widely used in transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions. They are the preferred equipment of modern logistics.
Products Features:
1. Moderate prices, a variety of models flexible configuration.
2. Hydraulic valve lock device international facilities, more secure and reliable.
3. 24 degrees Vicat sets of pipe joints, high-precision cold drawn tube completely solves the oil spill, imported cylinder seals more durable, floating three-point bridge better protects the automobile frames.
4. High strength steel production of lighter weigh, larger lifting, fully hydraulic, full rotation, using the new hydraulic support legs.
Main Technical Data of Telescopic Boom Truck-mounted Crane SQ6SA2：
| Model | SQ6SA2 | Rated Pressure Of Hydraulic System | 20MPa |
| Max Lifting Capacity | 6000Kg | Max Oil Flow Of Hydraulic System | 40L/min |
| Max Lifting Moment | 12.6T.m | Rotation Angle | 400° |
| Recommended power | 20KW | Crane Weight | 2100Kg |
| Oil Tank Capacity | 100L | Installation | 1050mm |
Main Technical Data of Telescopic Boom Truck-mounted Crane SQ8SA3：
| Model | SQ8SA3 | Rated Pressure Of Hydraulic System | 20MPa |
| Max Lifting Capacity | 8000Kg | Max Oil Flow Of Hydraulic System | 40L/min |
| Max Lifting Moment | 20T.m | Rotation Angle | 360° |
| Recommended power | 25KW | Crane Weight | 3500Kg |
| Oil Tank Capacity | 150L | Installation | 1500mm |
Main Technical Data of Telescopic Boom Truck-mounted Crane SQ10SA3：
| Model | SQ10SA3 | Rated Pressure Of Hydraulic System | 20MPa |
| Max Lifting Capacity | 10000Kg | Max Oil Flow Of Hydraulic System | 40L/min |
| Max Lifting Moment | 25T.m | Rotation Angle | 360° |
| Recommended power | 26KW | Crane Weight | 3800Kg |
| Oil Tank Capacity | 250L | Installation | 1500mm |
Main Technical Data of Telescopic Boom Truck-mounted Crane SQ12SA3：
| Model | SQ12SA3 | Rated Pressure Of Hydraulic System | 25MPa |
| Max Lifting Capacity | 12000Kg | Max Oil Flow Of Hydraulic System | 40L/min |
| Max Lifting Moment | 30T.m | Rotation Angle | 360° |
| Recommended power | 30KW | Crane Weight | 4000Kg |
| Oil Tank Capacity | 250L | Installation | 1600mm |
Main Technical Data of Telescopic Boom Truck-mounted Crane SQ16SA4：
| Model | SQ16SA4 | Rated Pressure Of Hydraulic System | 26MPa |
| Max Lifting Capacity | 16000Kg | Max Oil Flow Of Hydraulic System | 63L/min |
| Max Lifting Moment | 40T.m | Rotation Angle | 360° |
| Recommended power | 35KW | Crane Weight | 5800Kg |
| Oil Tank Capacity | 250L | Installation | 1600mm |
