Model:R-6-300
Detailed Product Description
Ring making and welding integrated machine
1.CNC control
2.Server motor driven
3.High precision
4.1200pcs/hr(150mm ring)
Ring making and welding integrated machine
Input voltage: 380V(3-phase) or customized
Power freq.: 50/60Hz
Rated power: 18KVA
Cooling: Natural cooling
Air flow: 250L/min
Air pressure: 0.6-0.8MPa
Wire thickness: 2.8mm-6mm
Max ring diameter: 300mm
Min ring diameter: a. 88mm (wire thickness less than 4mm) b. 90mm (wire thickness between 4 mm and 5mm) c. 105mm (wire thickness between 5mm and 6mm)
Throughput: about 1200pcs/hour(for ring diameter 150mm)
Ring diameter tolerance: less than 0.16mm
Weight: 1200KG
Features
Very robust and durable machine body
Length controlled by encoder, higher precision
Program-aided size change, quick and accurate
Servo motor inside, better precision and less maintenance than hydraulic system
Intelligent controlling system, easier program updating and function expanding
Comprehensive self-detection, machine will stop in cases of no wire, bad weld, etc.
Voltage can be customized to suit your power supply
