Model:YD5
Send Inquiry
| Power voltage(V) | 230 | 230 | 230 |
| Max input power(KVA) | 5.2 | 6.0 | 8.2 |
| Max input power(KVA) | 50/60 | 50/60 | 50/60 |
| Mains fuse(A) | 22 | 26.1 | 37 |
| Effciency(%) | 0.83 | 0.83 | 0.85 |
| Power factor | 0.7 | 0.7 | 0.7 |
| Max No load voltage(V) | 67 | 67 | 76 |
| Current range(A) | 10-140 | 10-160 | 10-200 |
| Max current(A) | 140@60% | 160@60% | 200@60% |
| Current at 60%(A) | 108 | 124 | 155 |
| Usable electrodes | 1.6-4.0 | 1.6-4.0 | 1.6-4.0 |
| Insulation class | H | H | H |
| Protection degree | IP21 | IP21 | IP21 |
| Measurement(mm) | 360*235*310 | 360*235*310 | 460*255*355 |
| G/N Weight(KG) | 5.4/4.5 | 6/5.4 | 9.8/8.5 |
| Cod.(NO) | 891123 | 891124 | 891125 |
