Vibration Welder

FEATURES
1. Electromechanical vibration head assembly (200-240Hz)
2. Super rigid four rail table slide system
3. One piece flame cut bridge (heaviest in class, in the industry)
4. Solid state 52HP digital vibration drive
5. Hydraulic lift/clamp force max. 7, 000 lbs. (31, 000 N), 20 gallon (75.6 L) reservoir
6. Allen-Bradley® Compactloqix controller with add-on expansion available
7. Allen-Bradley Panelview Plus 700 full color touch sceen HMI
8. Intuitive and interactive comprehensive help menu
9. Part parameter monitoring with programmable limits
10. Choice of multiple languages for menus
11. Automatic tuning
12. Programmable amplitude 0.040" to 0.070" (1.0 to 1.8mm)
13. Weld by time and weld by distance (absolute or meltdown)
14. Interior work light
15. Optical zero force cycle activation switches
16. Light Curtain for single switch activation
17. Less than 80 dB in operation (continuous measurement)
18. Dual external utility outlets

SPECIFICATIONS
1. Table size 72" x 24" (1800mm x 610mm) (also max. Tool size*)
2. Table opening 58" by 12" (1470 x 305mm) with max., depth 20" (500mm) (except F/B center strip 3" (75mm) wide with depth of 1/2"**(12mm)
3. Upper tool weight 110-200 pounds (50-90kg)
4. Low 41" (1040mm) lift table height
5. 20" (500mm) Stroke, 25" (630mm) Max daylight
6. Door opening 26" high x 76" wide (660mm x 1931mm)
7. Electric Service Required: 480V, 3 Phase, 40 Amps (custom input voltage kits available)
8. Pneumatic Service Required: 75 to 90PSI (5-6 Bar)
9. Approximate Shipping Weight 7800 lbs, (3546 kg)

APPLICATIONS:
1. Air Intake Manifold
2. Grab Handles
3. Vacuum Reservoir
4. Rear-Combination Lamps
5. Instrument Panel
6. Filter Bag
7. Surgical Reservoir
8. Exterior Trim Pillars
9. Fuel Pump.
