Model:SKFZ Series
Item Name: Shaking Sifter / Screener Model No:SKFZ Series
Function and Features:
This shaking screening device is designed for screening, sieving and deagglomerating. It has only one sieve, the sieve mesh is a wire mesh with square meshes. These meshes are square shaped (not round) and their available demensions are 0.25*0.25mm or 0.3*0.3mm or 0.35*0.35mm or 0.4*0.4mm, you can choose one kind of these dimensions according to your requirement. Comparing with rotary drum screener, the shaking screener is more suitable for screening the wood pellets--big pellets with small or broken ones (heavy materials), and rotary drum screener is more suitable for separating the wood chips and sawdust (light materials).
This device has the following features:
(1) High-capacity, robust design, Working stably and reliably
(2) Compact structure , saving space.
(3) easy maintenance , Quick-change screens
(4) Wide selection of sieve sizes
Key Technical Parameters:
| Model | Output (t/h) | Power(KW) | Shaking Frequency | Excitation Force | Screener Area(mm*mm) |
| SKFZ60*2C | 1.0-2.0 | 0.25*2 | 920/min | 3000kg | 1000*600 |
| SKFZ80*2C | 2.0-4.0 | 0.25*2 | 5000kg | 1500*800 | |
| SKFZ100*2C | 3-6 | 0.37*2 | 6000kg | 1800*1000 | |
| SKFZ120*2C | 5-8 | 0.37*2 | 6000kg | 2000*1200 | |
| SKFZ150*2C | 8-12 | 0.55*2 | 8000kg | 2200*1500 |
Range of application:This device is widely used in food, feed, chemical and medical industries and biomass fuel factory etc.
