Machine type:JCJX-17DL
Inverter Control:double inverter control
inlet dia(mm):2.0-3.5
outlet dia.(mm):0.4-1.2
max.dia no.:17
max. line speed(m/min):1200
body structure:ironed cast
drawing capstan:tungsten plasma capstan
slip ratio of machine(%):15
fix speed capstan ratio(%):10
main motor power:(kw):37
take-up motor(kw):7.5
capstan dia.(max)(mm):260
fix speed capstan dia(mm):260
take-up type:by Chain
take-up bobbin size(mm):500or630(aperture127)
traversing type:motor type
take-up type:shaftless type
tension control:air pressure type
lubrication type:full immersion
brake:discbreak/magnetic break
dimemsion(mm):10000*2500*3200
weight(kg):4500
