Model:DSG-03
e-mail:fiona_zhengyue@hotmail.com
skype:fiona_fsf
MSN:fiona_zhengyue@hotmail.com
Solenoid Operated Directional Valve,hydraulic valves,hydraulic solenoid valve
Detailed Product Description
The 50 design series DSG-03 solenoid operated directional valves have been deeloped bu improving various features of our current 3/8 wet type (DSWG-03)valve which alreday has a reputation for high pressure, high flow and high reliability.
These valves now have much larger flow capacities but lower pressure drop.
the DSG-03 50 series solenoid operated directional valv comes with two basic models:
Standard type -high pressure ,high flow
Shockless type- which greatly reduces noise and vibration of pipes during change over of spool.
The optimum valve for any system can be selected since many spool types and various solenoids are all available along with other optional features.
Fratures
1.Simple and Rational Structure
2.The Terminal Box is Suitable to the Electro-machanical Construction.
3.Electric conduit connection ports match the :modular age"
4.Light weight
5.Maximum Performance from the Wet Type Solenoids based on Continual Development
6.Having the Pressure Drop
7.Mounting/Removal of the valve is easy
Valve type | Model number | Max.flow L/min | Max.operating press.Mpa | Max.tank line back press.Mpa | |
Standard | DSG-03-3C | 120 | 31.5(spool type 60 is 25.0) | 16.0 | |
DSG-03-2D | |||||
DSG-03-2B |
Max.change over frequency cycles /min :AC ,DC ,RQ :240 R:120
Valve type | Model number | Max.flow L/min | Max.operating press.Mpa | Max.tank line back press.Mpa | |
Shockless type | S-DSG-03-3C | 120 | 16.0 | 16.0 | |
S-DSG-03-2D | |||||
S-DSG-03-2B |
Max.change over frequency cycles /min:120
Valves other than the types above are available ,please contact us for your requirement.
