Model:CEM650
Send Inquiry
| Model | CEM-650 | ||
| TRAVEL | LINEAR GUIDE WAY | ||
| X axis travel | mm | 600 | |
| Y axis travel | mm | 500 | |
| Z axis travel | mm | 250 | |
| Distance from table surface to spindle nose | mm | 120-370 | |
| TABLE | |||
| table area | mm | 600 x 500 | |
| Max. load of table | kgs | 200 | |
| T-slot | mm | 5 x 16 x 85 | |
| SPINDLE | 24000 RPM Standard | ||
| Spindle taper | ISO025(BT-30) | ||
| Spindle speed | rpm | 24000(30000) | |
| Spindle drive | type | Build in | |
| Spindle motor | kw | 4.5 (7.5) | |
| Spindle cooling | Oil cooler | ||
| FEED RATE | |||
| Rapid traverse(X,Y) | m/min | 24 | |
| Rapid traverse(Z) | m/min | 24 | |
| Cutting feed rate | mm/min | 1-7500 | |
| 3 Axes motor output(X,Y,Z) | kw | 0.8kw | |
| A.T.C. | |||
| Tool magazine capacity | pcs | 8 | |
| Max. tool diameter | mm | 40 | |
| Max. tool length | mm | 120 | |
| Max. tool weight | mm | 3 | |
| Tool selection | kgs | Fixed type | |
| OTHER | |||
| Power consumption | KVA | 15 | |
| Floor space(LxWxH) | mm | 1750 x2300 x 2450 | |
| Machine weight | kgs | 2800 | |
