Feature:

1.Various fuels are applicable, e.g. waste engine oil, diesel, waste vegetable oil, etc.

2.Flame adjustable freely by air-inlet controlling.

3.220V/50Hz & 110V/60Hz both available

4.Good fuel-air mixing,stable flame,high combustion efficiency and friengdly-envionment

5.Easy installation,Easy maintenance

Descriptions:

1. Oil consumption: 2 - 5 (KG/Hour)

2. Output heat power: 24-59 (KW)

3. Output heat: 20,400-52,000(KCal/h) / 80,000 -200,000 (Btu/h)

4. Distance from fire gun to flange: 173mm

5. Distance of screw bore in the flange: 160x160(mm)

6. Fire gun dia. 114mm or 100 mm

7. Compressed Air Pressure: 0.05-0.1MPa
