HR-900

INJECTION  UNIT

SCREW DIAMETER                    30  35  value="40" unitname="mm">value="40" unitname="mm">40      mm

SCREW L/D RATIO                     22  22  value="22" unitname="l">value="22" unitname="l">22      L/D

THEORETICAL SHOT VOLUME         117  159  value="207" unitname="cm">207   cm3

SHOT WEIGHT                        106  144  value="189" unitname="g">189   g

INJECTION PRESSURE                 252  185  142   Mpa

INJECTION RATE                      63  86  value="112" unitname="g">112     g/s

PLASTICIZING CAPACITY              9.2  13.5  value="18.8" unitname="g">18.8  g/s

SCREW SPEED                             240        r.p.m

NOZZLE TOUCH FORCE                    37         kN

STROKE OF NOZZLE                       value="220" unitname="mm">220        mm

CLAMPING  UNIT

CLAMPING FORCE                            900      kN

STROKE OF MOVING PLATEN                  value="310" unitname="mm">310      mm

MOULD THICKNESS(MIN-MAX)              130value="380" unitname="mm">-380    mm

SPACE BETWEEN TIE-BARS                 360*value="360" unitname="mm">value="360" unitname="mm">360     mm

HYD.EJECTOR FORCE                         34       kN

HYD.EJECTOR STROKE                       value="100" unitname="mm">value="100" unitname="mm">100       mm

NO.OF EJECTOR                               5+2     pc

OTHERS

PUMP MOTOR POWER                              11       kW

HEATING POWER                           6.4  7.6  8.8     kW

MACHINE DIMENSIONS(L*W*H)             4.3*1.2*value="1.8" unitname="m">1.8       m

MACHINE WEIGHT                                 3.2        t

HOPPER CAPACITY                                value="25" unitname="kg">25        kg

OIL TANK CAPACITY                              value="210" unitname="l">210        L
