Function and Features

The machine has the function of embossing and cutting raw paper into kitchen towel. The folding of product is “N” type folding and you can draw it one by one .This kind of towel is widely used in hotel, office and kitchen etc, which is convenient and sanitary.

We adopt original vacuum absorption technology, the adaptability of raw material is very strong .The folding, cutting, counting, etc, several processes are completed on the machine together.

1. Counting automatically and output products are in good order.

2. Adopting screw turning knife to cut and vacuum absorption to fold.

3. Adopt step-less adjusting speed to roll which may fix different tension of raw paper.

4. Control pneumatic with electric convenient to operate.

5. Capable of forming complete set of rolling figure unit with clear look.

6. Have a wide range of production width for user to sale conveniently.

 Technical Parameters

1. Production Speed: 60~value="100" unitname="m" w:st="on">100 m/min

2. Range of raw material:33value="47" unitname="g" w:st="on">-47g/ m² (single layer)

3.open size(L*W): 230*(220-240)MM

4.folding size(L*W): 80*(220-240)mm

5. Power: 15.5Kw (380V 50Hz) (For your reference, it depends on the power situation in your place)

6. Overall size (m): 4.1×1.3×2.1(L×W×H)

 Specification of raw material

1.       The width of raw material: value="460" unitname="mm" w:st="on">460mm

2.       The diameter of raw material: value="700" unitname="mm" w:st="on">700mmvalue="1000" unitname="mm" w:st="on">-1000mm

3.       The thickness of raw material : value="33" unitname="g" w:st="on">33g m²value="47" unitname="g" w:st="on">-47g/ m²

4.       The diameter of core: value="76" unitname="mm" w:st="on">76mm
