Model:TJ2000D
Send Inquiry
| Technical parameter | TJ1000 | TJ2000 | TJ3000 | |||
| Extruder | Screw dia D | mm | 70 | 90 | 100 | |
| Screw L/D | 24 | 24 | 30 | |||
| Screw speed, max | rpm | 80 | 70 | 85 | ||
| Screw drive motor | kw | 30 | 45 | 75 | ||
| Output capacity HDPE | kg/h | 85 | 160 | 230 | ||
| Connection load | kw | 15 | 66 | 85 | ||
| Number of heating zone | 3 | 4 | 5 | |||
| Blow mould | Mould length, max A | mm | 345 | 430 | 670 | |
| Mould width, max B | mm | 440 | 680 | 640 | ||
| Mould depth C | mm | 2x115 | 2x115 | 2x230 | ||
| Daylight opening D | mm | 296 | 300 | 600 | ||
| Clamping system | Horizontal stroke of clamping system | mm | 460 | 700 | 900 | |
| Dry cycles | Sec. | 2.9 | 4 | 6 | ||
| Clamping force | KN | 90 | 125 | 200 | ||
| Other | Calculation of water consumption | L/h | 2200 | 3500 | 5500 | |
| Pressure air requirement, approx. | L/min | 1800 | 3000 | 4400 | ||
| Operating pressure,(hydraulic) | Bar | 120/160 | 120/160 | 120/160 | ||
| Operating pressure,(pneumatic) | Bar | 6~10 | 6~10 | 6~10 | ||
| Power distribution | Power of die heating | kw | 5.7 | 18.5~20 | 28 | |
| Oil pump motor 1 | Kw | 15 | 30 | 30 | ||
| Oil pump motor 2 | kw | ----- | 7.5 | 11 | ||
| Max energy consumption of total machine | kw | 30 | 90 | 110 | 130 | |
