Model:NC-002
Numeric Chocolate Depositing Machine
What is numeric chocolate depositing machine?
1, Above all, the machine should guarantee the moulds can be free running on the belt but not locked. Adopt servo control system and identify of position system to make moulds run in a exactitude positon without any mistake.
2, The nozzles controlled and managemented by 3D(x,y,z-axes) running system, so that the machine can fix into any flexible products requirements.
3, According to chocolates' detailed specification which will be processed through set up by software and can be saved.
Flexible and simple handle by software design, cost saving.
4,Stable and high capacity, meet factories requirements.
Differences between the traditional and new numeric depositing machine:
Items | OldTraditional Depositor | New Numeric Depositor |
Moving of conveyor belt | Motor driving, inaccurate | Servo system control, accurate |
Moving of depositing nozzles | Stepper motor control only vertical moving | Servo system control, accurate 3D moving. |
Moulds & trays assembly | Being locked on the conveying chains, locating by the motor step. | Movable and changeable, queuing on the conveyor belt, locating by the proximity switch. |
Hardware structure | Special designed, different parts closely related. | Modular, distributed. Standard and changeable. |
Software structure | Simple, attached to the mechanical hardware. | Modular design, powerful and intellectual brains to the hardware. |
Production technology | Being changed or adjusted through the mechanical hardware. | Easily to be changed or adjusted through the software. |
Technical Descriptions:
1. Multifunction, all are applied and switched through software.
Depositing:forming or moulding various shapes matched with moulds.
Filling:filling sandwich coated with chocolate.
Miscellaneous:adding nuts,rice,cookies inside, coated with chocolate,and so on.
2. Modular struture,flexiable manufacturing system (FMS):
Control center: PLC plus touch screen.
Sub-systems: servo moving systems, temperature preservation systems;cooling and conveying systems.
All components and modules are standard and changeable easily.
3. Accurate and high-speed moving.
Piston moving precision:0.005mm;
Minimal resolution of pumps:0.1ml;
Continuously adjustable moving gears: 0%-100% the full speed.
4. Friendly interface, easy to operate.
Easy to program: the way of teaching and playback;
All products patterns can be saved and applied anytime through the software.
5. Stable running and high output.
All components are validated to industrial standards.MEBF (mean time between failures) is 5000 hours.
High speed servo system are moving with 48 nozzles efficiently, no bottleneck restrictions.
6. No harmful to envrionment and energy-saving.
No any harmful emissions, no heavy mental pollution or halogens.
All material and components are degradable and recycleable.
Equipped capacitor: AC220V,50/60Hz,6KW/one machine
