Details of 244E:

Engine

Model: KM385TE
Type: 3 CYLINDER VERTICAL ,WATER COOLED 4 STROKE ,SWIRL DIESEL,

Rated power(KW):17.6KW ,24 HP

Rated rotation speed(r/min): 2350 rpm

Transmission

Speed range(km/h):

          Forward 1.73/3.42/5.7/7.99/15.79/26.35/28.86

          Reverse:1.37/6.34

Tractor

Wheel base(mm): 1645

Front wheel tread/Rear wheel tread(mm): 1100/1200-1400

Tyre size(front/rear): 6.0-16/9.5-24

PTO shaft rotating speed(r/min): 540/1000

Rated tractive force(kN): 5.98
3 Hitch Type:category 0
Clutch:dual clutch
Overall dimensions

LXWXH (mm): 3185x1440-1460x2530
