Type:                                      KY152F
Bore x stroke:                       52x 46mm
Displacement:                     97.7ml
Compression ratio:            5.6:1
Maximum power:                2.5hp (1.85kW)/3,600rpm
Rated power:                       1.6hp (1.2kW)/3,600rpm
Maximum torque:                3.6N.m/2,600rpm
Fuel tank capacity:              1.8L
Engine oil capacity:             0.4L
Oil consumption:                 450g/kWh
Ignition system:                   transistor magneto
Starting system:                  recoil start
Engine types:                      single-cylinder, Valve sided, four-stroke and forced air-cooled
Net/gross weight:               9/10kg
Dimensions:                      300 x 295 x 365 mm
