The JM3 is a high-performance heavy duty electric winch and is ideal for materials and equipments loading. 3000 kg line pull capacity.  Features an column gear speed reducer, integrated sealed switching controller, dynamic hydraulic/ electromagnetism brake, and three phase asynchronism  crane motor. Steel welded drum with flange.

Features:

• Switch controller with forward, stop and reverse
• Switching Method:  Hand turn control
• wires with steel cover protection
• Uses 3 wires to power supply connection
• 3000 kg line pull capacity
• Drum capacity 16mm x 180m  ropes
• Braking:  Electric dynamic hydraulic brake, can stop the drum when power loose, also can plus mechanical brake.
• With bolt holes on bottom for mounting.
• Shipping weight 1000kg
• Apprance size: 1775mm(L) x 1150mm(W) x 1100mm(H)
• Motor:7.5kw,380v,3P,50HZ,

Also we can supply various 1ton to 50ton winches, like double drum, fast speed, free fall and so on.

3ton wire rope winch, power winch for construction,building
capacity from 3ton to 50ton, safety,
high cost performance,
perfect technolog
