Crimped Curving Machine, Hydraulic Curving Machine, Curving Machine, Auto Curving Machine
A) Technical Data

l        Raw material thickness: 0.23value="0.5" unitname="mm">-0.5mm

l        Raw material width and length: according to customer's request

l        Working Speed: 0value="10" unitname="m">-10 m/min ( adjustable)

l        Main Power: 0.85 Kw

l        Hydraulic Power: 5.5 KW

l        Roller material: High grade 45# forged steel, surface polished and coated with value=".05" unitname="mm">0.05mm thickness hard chrome

l        Shaft material: high grade 45# Steel with Diameter value="75" unitname="mm">75mm

l        Cutting Blade: Cr12 mould steel with quenched treatment

l        Control: Panasonic Brand PLC computer control ( frenquency convercy )

l        Size of PLC Control Board: value="700" unitname="mm">700mm(L)xvalue="1000" unitname="mm">1000mm(H)xvalue="300" unitname="mm">300mm(W)

l        Dimension of machine: value="3200" unitname="mm">3200mm(L)xvalue="1600" unitname="mm">1600MM(W)xvalue="1500" unitname="mm">1500mm(H)

l        Minimum Curving Radius: value="450" unitname="mm">450mm

l        Max Curving Angle: 120 Degree

l        Effective Width of Sheet: value="585" unitname="mm">585mm

l        Machine Weight: about 3.5 Ton
