Detailed introduction to Standard specifications U type mosi2 electric stove heating elements:
Molybdenum disilicide (MoSi2) heating elementis a resistance generate-heating component made from MoSi2
or the basic material. It is used in high temperature under the oxidizing atmosphere, it looks like glass in its surface
and form a light SiO2 glass film which can protect the element not to be oxidized. So this kind of element has unique
effect for resisting oxidization in the high temperature. It is used to the highest temperature up to 1800C during oxidizing
atmosphere. According to your request, our company can produce the products of Pole, "U", "W" and "U"-right
angle shapes, etc.
MoSi2 heating element can usually make use of furnace temperature from 1300C to 1800C. It is extensively used in the
industries of metallurgy, glass, ceramic refractory, crystal electronic device, industrial furnace manufacture, etc.. It is an
essential ideal element when the products are sintering in the high temperature.
Specification
|
| 1700°C Grade | 1800°C Grade | ||||||||
| d/c (mm) | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 | 3/6 | 4/9 | 6/12 | 9/18 | 12/24 |
| Le Max,mm | 350 | 450 | 1400 | 1400 | 1700 | 350 | 450 | 1400 | 1400 | 1700 |
| Lu Max,mm | 300 | 450 | 1000 | 1000 | 1000 | 300 | 450 | 1000 | 1000 | 1000 |
| a (mm) | 25 | 25 | 40/50 | 60 | 80 | 25 | 25 | 40/50 | 60 | 80 |
| f (mm) | 25 | 25 | 45 | 75 | 100 | 25 | 25 | 45 | 75 | 100 |
| g (mm) | 15 | 15 | 25 | 30 | 40 | 15 | 15 | 25 | 30 | 40 |
| Nonstandard shape & size could be made according to your requirement | ||||||||||
Notice to Furnace Operation:
To avoid high current surges which may cause damage to MoSi2 heating elements, the recommend starting
procedure as following:
