Detailed introduction to CO2 Laser Engraving Machine for Anodized Aluminum:

CO2 Laser Engraving Machine for Anodized Aluminum

Laser Engraving Machine JG-7040SG

(1)Product Features

1. Honeycomb and aluminous strip panel double-face working table is suitable for processing different kinds of materials.

2. Automatic up and down working table, easy and flexible operation.

3. Equipped with Ultrasonic Auto-focus System to meet different processing demand.

4. Humanism closed designed system for top and bottom exhaust, ensures the safety of the processing, worriless whole-process.

5. Equipped Rotary attachment for engraving cylindrical objects.

(2)Application

Applicable Materials: Wood, Plywood, Bamboo, MDF, Balsa, Wood Veneer, Acrylic, ABS, Plastic, Perspex, Plexiglass, PMMA, Glass, Rubber Sheet, Double Color Plastic, Paper, Cardboard, Cardboard, Paperboard, Leather, etc.

Applicable Industries: Advertising Industry, Signs, Promotional Items, Crafts & Gifts, Plaques, Trophies, Awards, Bangles, Badges, Tags, Key Chains, Souvenirs, Precise Ornaments, Architecture Modeling, Furniture, etc.

(3)Technical Parameter

1) Laser Type:

A  CO2 DC Glass Laser Tube

B  CO2 RF metal Laser Tube

2) Laser Power:  A: 50W / B: 30W

3) Working Area:  700mm×400mm

4)Working Table:  Honeycomb and aluminous strip panel double-face working table

5) Engraving speed:

A  30000mm/min

B  72000mm/min

6) Repeat Precision: 0.05

7) Up and Down Scale of Work Table:     Automatic up and down distance: 0-150mm

8) Motion System:

A  5 inches LCD display, Offline stepping control system

B  Servo motor control system


9) Power Supply:  AC 110V-220V/50/60Hz

10) Format support: AI, BMP, PLT, DXF, DST, etc.

11) Standard Device:  Water cooling and protection system, Mini air compressor, 550W exhaust fan

12) Optional Device: Rotary attachment, Ultrasonic automatic focus system, Red cross positioning system, Constant temperature water chiller

13) Machine Dimension (M): 1.42×1.12×0.98

       Packing Dimension (M): 1.50×1.20×1.12

       Net Weight (KG): 245

       Gross Weight (KG): 295

Versatile Laser Engraving Machine:

Working size and laser power can be customized according to requirement.
