Model:PA
Send Inquiry
Detailed introduction to PA electric trolley:
Can be matched with 68mm-110mm I beam
| Model | TD0.5 | TD1 | |
| WLL (ton) | 0.5 | 1.0 | |
| Proof load (ton) | 0.6 | 1.2 | |
| Standard lifting height (m) | 3M | 3M | |
| Lifting speed (m/min) | 16.4 | 16.4 | |
| Motor Parameter | Motor type | D025034 | D026324 |
| Power | 60W | 120W | |
| Rotate speed | 1400r/min | 1400r/min | |
| Diam of min curve it can pass through | 1 | 1 | |
| I beam suggested | I beam type | 10-22 | 10-25 |
| Track width | 68-110 | 68-110 | |
| N.W. (kg) | 14 | 16 | |
