Detailed introduction to Vacuum Ceramic Disc Filter:

Vacuum Ceramic Disc Filter is the solid/liquid separation equipment, used to dewater mineral concentrates and pelletizing feed slurries. Micro porous ceramic discs replace conventional filter cloth.

important Features of Our Vacuum Ceramic Disc Filter:

1. High vacuum degree with maximum of -0.098MPa, low moisture of filter cake, normally 2-4% lower than moisture of the cake by traditional filters;

2. Low power and energy consumption, 10-20% of that of traditional filters;

3. Clear and transparent filtrates. Solid content is normally lower than 21mg/l and filtrate can be recycled or disposed of without harm to the environment;

4. Little pollution, environmentally friendly, safe and reliable;

5. Ceramic Filter Plate is long service life, easily replaced and doesn't require intensive labor work;

6. Dewatering cost is normally 18.8-40.1% of that of traditional filters;

7. Automatic and continuous operation, low maintenance cost, high filtration efficiency;

8. Lower metal loss and higher metal recovery;

Application area:

VCDFs are widely used in the beneficiation of such ore concentrates as Iron ores, Gold, Copper, Copper Sulfide, Nickel, Zinc, Lead, Molybdenum, Phosphorus, Sulfur, Quartz Sand, and Fluorite. A complete and up-to-date customers list will be provided upon request.
