Model:SZL7-1.0-AII
Send Inquiry
Detailed introduction to ASME hot water boiler:
| ItemType | SZL2.8-0.7/95/70-A II | SZL4.2-1.0/115/70-A II | SZL5.6-1.0/115/70-A II | SZL7.0-1.0/115/70-A II | SZL10.5-1.25/115/70-A II | SZL14-1.25/130/70-A II | |
| Rated capacity MW | 2.8 | 4.2 | 5.6 | 7 | 10.5 | 14 | |
| Rated working pressure Mpa | 0.7 | 1.0 | 1.0 | 1.0 | 1.25 | 1.25 | |
| Supply water temperature C | 95 | 115 | 115 | 115 | 115 | 130 | |
| Return water temperature C | 70 | 70 | 70 | 70 | 70 | 70 | |
| Circle flow m3/h | 96 | 80 | 106 | 133 | 200 | 200 | |
| Heated area M2 | radiation/convection | 15.6/112 | 21.6/132 | 25.2/171.5 | 29.5/204.1 | 37.21/284.68 | 58.4/307.4 |
| Heat efficiency % | 81 | 78 | 78 | 79 | 79 | 79 | |
| Fuel consumption kg/h | 658 | 1033 | 1367 | 1688 | 2530 | 3375 | |
| Effective area of grate m2 | 6.4 | 7.8 | 10.04 | 11.8 | 17.81 | 22.56 |
