New Roc plate heat exchangers are developed, designed and manufactured according to State standard, available in various series with over 60 types of plates like those with deep wave and shallow wave, for condensation and evaporation, adopting free flow channel and gasket without glue and different flow channels for selection by the user. Besides, the company is capable in designing and manufacturing plate heat exchangers for special need of the buyer and also the substitute of foreign makes.
Not only can we provide you with plate heat exchager ,but also we can help you to choose suitable one according to the parameter offered. We engage in design, development, manufacture and consulting service. Our plate heat exchanger can be used in the field of air-conditioner, electric power, petroleum chemicals, boats and ships, food and drinks, iron and steel , recycling of the heat. We dedicate ourselves to the design, manufacture and service of the PHE, providing a solution and high-quality products and service for clients according to different fields and conditions.
Diversified Channel Design
| Low angle channel arrangement(L+L) For lower allowable pressure drop requirement applications. | |
| High angle channel arrangement(H+H) For higher thermal performance and alloable pressure drop requirement applications. | |
| Mixed channel arrangement(H+L/H+M/M+L) Optional arrangement to gain the optimized performance. |
http://www.newrocindustrial.com/index.php?m=content&c=index&a=show&catid=10&id=2
Specification.
| Max.flowrate | 4600m3/h | Max.unit area | 2200㎡ |
| Connection | DN25~DN500 | Design pressure | 1.0MPa;1.6MPa;2.5MPa |
| Design temp | -20℃~180℃ | Max.design Pres | Max.2.5MPa |
