Name

Specification

Raw material of the die

P20/5CrNiMo/2738 from GERMANY

Polymer to be processed

PE/HDPE/LDPE/PA/PS/PP/LDPP/HDPP/ABS/EVA/PC/PMMA

Sheet  thickness

0.015-0.2mm          adjustable

Sheet  width

700mm-4000mm   adjustable

Lips

Upper lip can be micro adjusted，down lip can be adjusted

Flow channel

Coat hanger

Heating Voltage

220v or others you need

Heating unit

Heating bars made of stainless steel

Cable connection:

Close connecting with protection cover

Screws

High strength at 12.9 grade

Polishing

Lips and surface of flowing: 0.02－0.03(μm),

Other surfaces: 0.03－0.04(μm).

Electroplating

Lips and surface of flowing harden treatment by chrome plating.

Plating thickness: 0.03-0.04mm Hardness: 60-65HRC.

Other surface plating thickness: 0.01-0.02mm

Feeding

Round center feeding

Installation

/confirm/ied by buyer

Standard  Accessories

Heating bar,screw,other tools,manual book

Payment:

50% down payment paid by TT upon order signed

50% to be paid before delivery

Delivery:

30-45 days after down payment.
