Wire rope cable puller:
Lifting capacity: 0.8T/1.6T/3.2T
Wire rope standard diameter: 8mm/11mm/16mm
Efficient, safe and durable hoisting machinery
Aluminum alloy, long service life, light, easy to operate
Has the lifting, traction, tight 3 big functions.
Apply to baoche traction, communication, constructing the pipe laying, power installation,
Tunnel and deep well assignments, oil field, railway traction, more extensive applic.
| Item No | WRP08 | WRP16 | WRP32 |
| Lifting Capacity (Kg) | 800 | 1600 | 3200 |
| Pulling Capacity (Kg) | 1300 | 2800 | 6000 |
| Tested (Kg) | 1500 | 3000 | 6000 |
| Steel Wire Rope Dia. (MM) | IWRC 8.3 | IWRC 11 | IWRC 16 |
| Wire Rope Safety Factory Load Capacity (MM) | 5×WLL | 5×WLL | 5×WLL |
| Breaking Strength of Wire Rpoe (Kg) | 5430 | 9680 | 17200 |
| Overall Structure Breaking Strength | 4×WLL | 4×WLL | 4×WLL |
| Ransmission | 3mtrs | 3mtrs | 3mtrs |
| Net Weight (without wire rope)(Kg) | 6.4 | 12 | 23 |
