YYSL-Ⅱ Double-cylinder Double-doffer Carding Machine

Uses and characteristics: It is suitable for carding of 1.5-20D×38-65mm artificial fibre. The fiber is carded fully so that the mesh becomes more even through the double-cylinder carding at high-speed. Feeding roller is driven by frequency conversion and it is equipped with anti-metal protection device.

Main specifications:

Machine width: 1550mm,1850mm, 2000mm, 2300mm, and 2500mm

Primary cylinder: φ850mm

Main cylinder: φ1230mm

Middle doffer: φ635mm

Output doffer: φ492mm

Output speed: 20～50m/min

Cotton stripping: roller

Power: 25kw
