Model:AAC cutter
Cutting machine is main equipment in aerated concrete production. The annual capacity of aerated concrete production is above 50000 cubic meters. Cutting machine is the core equipment, and the indispensable equipment in improving the production quantity. The JQF series cutting machine we produced can cut the porcelain body implement one pace reachs the designated position, and six sides flip. Because of its advanced technology, and not needing secondary hoisting, it reduces the damage to toporcelain body for the time after time hoisting. Therefore, the products are sold well all over the country, and high praised by vast users. After so many years continuous innovation, our factory developing up to now has produced various models of concrete cutting machine.
Aerated concrete cutting machine working principle: put aerated concrete porcelain body along with baseboard onto overtable, then move the small slide set to the direction of cutting machine, after turning 90 degrees small slide will move porcelain body to cut position, firstly the all around cutting, then the longitudinal cutting. The cutted porcelain body will be moved again by small slide to overable, flipping porcelain body 90 degrees to reverse direction on the reverse. The whole process automatically.
The advantages of the ground flipping cutting machine our company produces:
1, compact structure, easy to operate, small amount of maintenance.
2, the porcelain body horizontal and vertical cutting finished at one time.
3, the porcelain body for six surface cutting. Products precision reaches GB/T11969-1997.
4, can satisfy the plank production requirements, and the product precision can reach GB15762-1995.
5, waste recycles all, no secondary pollution.
6, porcelain body do not adhibit.
7, crosscut adopts screw transmission, resolving the not synchronization problem of hydraulic transmission.
8, mechanical system no limit and interlock, can prevent the equipment accidents in improper operation.
9, has replace steel wire rapidly device.
10, no "double-fold eyelid" and "side damage" phenomenon.
The Main Technical Parameters of Cutting Machine
Serial number | Size | Semifinished prsduct befcre cutting | Cutting cycle about | Cutting ability(m3/year) | Cutting precision (mm) | Cutting precision(kw) | Type outine size(mm) |
1 | 4M | 4040×1240×650 | 6 min/mold | >100,000 | Six-side cutting | 26.5 | 1100×4200×5600 |
2 | 6M | 6050×1540×650 | 6 min/mold | >100,000 | Six-side cutting | 30 | 13200×4600×5800 |
