tank welding rotator YZK- conventional type - Sell

tank welding rotator YZK- conventional type

2016-10-30 18:56 Views:253

Price:Negotiable
Model:YZK

Type	Maximum load weight(kg)	Diam.of suitable workpiece(mm)	Diam.and width of wheel(mm)	Liner speed of wheel(m/h)	Power of motor(kw)	Way of setting
Rubber rollers	metal rollers
YZK-3	3000	φ250-φ1800	φ200x100	2 x φ194 x 20	6-60	2 x 0.25	AC converter or electromagnetic speed control
YZK-5	5000	φ250-φ2300	φ250x100	2 x φ240 x 20	6-60	2 x 0.37
YZK-10	10000	φ320-φ2800	φ300x120	2 x φ290 x 25	6-60	2 x 0.55
YZK-20	20000	φ500-φ3500	φ350x120	2 x φ340 x 30	6-60	2 x 1.1
YZK-30	30000	φ600-φ4000	φ350x120	2 x φ340 x 30	6-60	2 x 1.1
YZK-40	40000	φ600-φ4200	φ400x120	2 x φ390 x 40	6-60	2 x 1.5
YZK-50	50000	φ750-φ4500	φ400x120	2 x φ390 x 40	6-60	2 x 2.2
YZK-60	60000	φ750-φ4800	φ450x120	2 x φ440 x 50	6-60	2 x 2.2
YZK-80	80000	φ850-φ5000	φ500x120	2 x φ490 x 60	6-60	2 x 3
YZK-100	100000	φ1000-φ5500	φ500x120	2 x φ490 x 70	6-60	2 x 3
YZK-160	160000	φ1100-φ6000	—	φ620x220	6-60	2 x 4
YZK-250	250000	φ1200-φ7000	—	φ700x280	6-60	2 x 5.5
YZK-500	500000	φ1500-φ8000	—	φ850x350	6-60	2 x 7.5
YZK-630	630000	φ1500-φ9000	—	φ900x380	6-60	2 x 11
