Wood/biomass pellet machine, Professional and newly machine for wood/biomass/rice husk/straw pellet making.

Application:

Flat die pellet mills are generally used for pellet production on a small to medium scale. Flat die pellet mills can process a wide range of biomass materials, for a range of applications. These include wood, straws, grasses and other biomass residues. And also for animal feedstuff.

Raw material for the pellet mill must have passed through sufficient size reduction before it can be placed in the pellet mill. The raw material must have a particle size of 3-5mm or below.

Key specification and quality warranty:

Heart parts of the pellet machine- die and roller are made by high alloy steel wear resistant material according to different materials, in order to have longer work lifetime .

Wood/biomass pellet machine with double layer dies , up and down dual-use, reduce buyer’s cost, so it can reach high capacity , also energy saving .

12months limited warranty for electric parts ,

Average lifetime for die and rollers:

2000 hours for SK-350/450/550/800/1000,

800-1000 hours for SK-200/250/300.

Technical parameters:

1.Model: SK-450II

Capacity: 700-1000kgs/H

Power: 45KW

Drive way : Gear box

Diameter of pellets:6-20mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Diameter of the die: 450mm

Weight: 800kgs

Dimention: length:1600mm , width:1400mm ,height:800mm

2.Model: SK-550II

Capacity: 1000-1200kgs/H

Power: 55KW

Drive way : Gear box

Diameter of pellets:6-30mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Diameter of the die: 550mm

Weight: 1000kgs

Dimention: length:1700mm , width:850mm ,height:1600mm

3.Model: SK-1000II

Capacity: 2000kgs/H

Power: 132KW

Drive way : Gear box

Diameter of pellets:6-30mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Diameter of the die: 1200mm

Weight: 6000kgs

Dimention: length:2500mm , width:1400mm ,height:2000mm

4.Model: SK-1200II

Capacity: 3000kgs/H

Power: 160KW

Drive way : Gear box

Diameter of pellets:6-30mm

Pellet length: which can be adjusted by adjusting knife within range of 1-5cm .

Diameter of the die: 1200mm

Weight: 6000kgs

Dimention: length:2500mm , width:1400mm ,height:2300mm
