Woodworking cnc engraver with auto tool change
Model
RWD1530

Working Area (XxYxZmm)
1500x3000x300mm

Max Moving Speed
60000mm/min

Max Engraving Speed
25000mm/min

frame
Welded Steel

Spindle Power Motor
9kw
Option:3-12kw

Spindle Speed
6000-24000rpm

The number of knife
8pcs
According to demands

The manner to change knife
In-line
Option: Circular disk

XYZ traveling positioning accuracy
±0.04/300mm

XYZ repositioning accuracy
±0.04mm

Working Voltage
AC380V/50/60Hz,3Ph

Drive Motors
Servo Motors and Drivers

Command language
G code

Operating system
Syntec, system
(option: LNC control System)

Interface
USB

Flash memory
128M(U Disk)

Software Compatibility
Type3,Ucancam, Art cam Software

Diameter of tools
Φ3.175,Φ6, Φ12.7
