General Introduction:

HY-CRI200 High Pressure Common Rail Test Bench is kind of special equipment which is newly independent researched used to test common rail injectors and pumps. It is controlled by industrial computer. This test bench adopts original Bosch CP3.3 high pressure pump to generate 0~2000bar pressure, and common rail injectors and pumps of Bosch, Delphi, Denso, and Siemens can be tested.

1. ISO9001:2008 Certificate & CE Certificate.
2. Power: 5.5kw
3. Frequency Converter 5.5KW
4. Voltage: Three phase four wire, 380V
5. Main frame: Aviation Aluminum Structure.
6. Cast Iron Operation Platform. Low Noise.
7. Electric System: DELIXI or CHINT.
8. Common Rail pipe: Bosch
9. High pressure pump: Bosch CP3.3
10. Tertiary filter, filtering precision: 5um.
11. Revolving speed: 0~1000r/min.
12. Testing types: Injectors of Bosch, Denso, Delphi, and Siemens.
13. Net weight: 400kg.
