Introduction to the Floatation Machine:
The floatation machine is used for coarse separation, sweet separation and anti-floatation industrition of copper, lead, zinc, nickel, molybdenum and other non-ferrous metals, ferrous metals and non-metallic minerals.
Main Freatures of Flotation Machine:
- large air-absorption capacity
- low energy consumption
- three functions: air-absorption, slurry absorption, floatation separ
Technical Parameters of Model SF Flotation Machine:
Model | SF0.37 | SF0.7 | SF1.2 | SF2.8 | SF4 | |||||||
| Tank Volume（m3） | 0.37 | 0.7 | 1.2 | 2.8 | 4 | |||||||
| Impeller Dia（mm） | 300 | 350 | 450 | 550 | 650 | |||||||
| Capacity（m3/min） | 0.2- 0.4 | 0.3- 0.9 | 0.6- 1.2 | 1.5- 3.5 | 0.5 -4 | |||||||
| Impeller Rotate Speed（m3/min） | 352 | 400 | 312 | 268 | 238 | |||||||
| Motor | Model | ①Y90L-4 | ①Y100L2-4 | ①Y132M2-6 | ①Y160L-6 | ①Y180L-6 | ||||||
| ②Y90S-4 | ②Y90S-4 | ②Y90S-4 | ②Y90S-4 | ②Y90L-4 | ||||||||
| Power（Kw） | ①1.5 | ①3 | ①5.5 | ①11 | ①15 | |||||||
| ②1.1 | ②1.1 | ②1.1 | ②1.1 | ②1.5 | ||||||||
| Overall Dimension（mm） | 700×700 ×750 | 900×820 ×950 | 1100×1100 ×1100 | 1700×1600 ×1150 | 1850×2050 ×1200 | |||||||
| Unit Weight（kg） | 468 | 600 | 1373 | 2338 | 2660 | |||||||
Technical Parameters of XJK Series Flotation Machinery：
Model | XJK-0.35（3A） | XJK-0.62（4A） | XJK-1.1（5A） | XJK-2.8（6A） | XJK-5.8（7A） | ||
| Effective Volume（m3） | 0.35 | 0.62 | 1.1 | 2.8 | 5.8 | ||
| Capacity（m3/min） | 0.18～0.4 | 0.3～0.9 | 0.6～1.6 | 1.5～3.5 | 3～7 | ||
| Rotate Speed（r/min） | 470 | 400 | 330 | 280 | 240 | ||
| Impeller Dia (mm) | 300 | 350 | 500 | 600 | 750 | ||
| Motor | Model | Rotator | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y200L2-6（Y225M-6） |
| Scraper | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | ||
| Power（Kw） | Impeller Motor | 1.5 | 3 | 5.5 | 11 | 22（30） | |
| Scraper Motor | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | ||
| Weight：（t/Single Tank） | 0.43 | 0.86 | 1.38 | 2.33 | 3.533 | ||
