Price:Negotiable
Model:KMY299B-G

Send Inquiry

Front panel dimension: 392*110mm

contact person: leon@kmychina.com.cn

Material:

Front Panel: High quality 304# stainless steel
Keys: High quality 304# stainless steel
Trackball: High quality 304# stainless steel
Back panel: Aluminum alloy

Mechanical data:

Key trip: 1.5mm
Key pressure: 0.8~1.6 N
Lifespan: >2 million operations per key
Gross Weight: 2.0 KGS

Electrical data:
Input Voltage: 5.0VDC± 5%
Electric Current: 10mA
EMC Emission: EN55022
ESD Standard: Air Discharge 8KV; Contact Discharge 6KV

Environmental Adaptability:

Operating Temperature: 0° ~+60°
Storage Temperature: -25° ~+80°
Relative humidity: 30%~90%
Atmospheric pressure: 60~106 KPa

Reliability:
MTBF: >20, 000 hours
MTTR: < 30 minutes
CE, FCC, RoHS, ESD compliant
Waterproof and Dustproof class: IP65 (front panel)
Vandal resistant class: IK07.
