SZ-1B Hand held butt welder / SZ-1B 0.12mm-0.65mm cable welding equipment / cable welding device

Main parameters

1. Application: Widely used in the cold welding for the wire of copper, aluminum, and other non-ferrous metals

2. Welding Range of Copper wire: 0.12-0.60mm

Aluminum: 0.12-0.65mm

3. Structure: High-grad Stainless Steel

4. Advantage: No power, no change of the resistance, clean, light, thin deposit, easy of operation, portability

5. Overall dimensions:150*65*90mm (L*W*H)

6. Net Weight:1.1KG, package weight: 2.3KG

7: Package: beautiful aluminum case

8. HS code: 8515800090

9: MOQ: 1 SET

Main benefits of using cold welding:

The process is quick, reliable and cost-effective. The weld cycle takes only seconds to complete and creates a permanent bond stronger than the parent material, without using heat, fillers or fluxes.
