Model No.:YKD-10010
Product Origin:China
Brand Name:Yikangda
Price Terms:FOB Shanghai, CIF
Payment Terms:T/T, L/C at sight
Certification:ISO9001
Description:Specifications: 1) Raw material: a) Rolling welded steel tube: 4.76 ~ 6.35 x 0.71b) Low carbon steel wire: 1.4 ~ 1.6mmc) Bracket: steel plate SPCC thickness 0.6~2.0d) base mounting plate: SPCC thickness 0.6~2.02) Technical standards: can produce according to clients' drawing or samples3) Performance: a) Surface with electrophoresis coating to prevent the corrosionb) Inner cleanness can meet the requirement of R134a and CFC cooling systemc) Can satisfy the cooling capability requirementsStructure:1) Flat type of wire on tube condenser used at the back2) Bended or spiral type of wire on tube condenser used at the bottom3) Wrapped type of tube embed on plate4) Flat type of louvre condenser used at the backR134a cooling system tube inside standard:1) Residual moisture: ≤20mg/m22) Residual dusty: ≤30mg/m23) Residual mineral oil: ≤7mg/m24) Residual chlorine: ≤3mg/m25) Sealing density: ≥1.65MPa Specification of E-coating:1) Coating thickness: a) Thickness of anodic electrophoresis coating: ≥12μmb) Thickness of cathodic electrophoresis coating: ≥20μm2) Hardness of coating: ≥2H3) Impact of coating: 50cm.kg/cm impact, no crack4) Adhesion of coating: ≥2 grade5) Flexibility of coating: around R=3D bend 180 degrees, no crack or no fall off6) Corrosion resistant (salt spray GB2423)a) Anodic electrophoresis coating: ≥24hrsb) Cathodic electrophoresis coating: ≥96hrsPacking:Standard export carton and wooden pallet
