Functions and features
1. Automatic break protection for power leakage and short circuit;
2. Under-pressure protection: when incoming air's pressure is 0.5MPa, the equipment will be automatically stopped;
3. Water-shortage protection: when the level of the water tank is lower than that of the liquid switch, the equipment will be automatically stopped.

Remarks:We can add other functions as customer's requirements like:hot tank heating washingbottle external washingcap washing capacity note and man-machine control.

Main Technical Standards
Model JND100
Output :1200BPH
Voltage: AC220V/380V±5% 50HZ/60HZ
Rated Power: 24.8KW
Washing heads: 6x13
Filling heads:8x1
Capping heads:1x1
Bottle size : 270×490×56 mm
Cap size: 58×40(Tail: L×W=18×7.5) mm
Air pressure: 0.50.6MPa
N.W.: 2600Kg
Overall Dimension(MM) : 6200×2060×2300 2000×1900×2500
