CNC Cutting Machine
2016-10-28 22:59 Views:63
Price:Negotiable
Send Inquiry
| Product Name:CNC cutting machine |
| Model:QC12K |
| Materials:Steel and iron |
| Size:6x2500 |
Category:Shears
| | Performance and feature of CNC cutting machine
1, host adopts hydraulic plate shears QC12Y structure of nc system, MD320 control system,
2 MD320 control system, control system, MD320: by frequency drives, servo motor components closed-loop control.
3, directly to the position of programming, can undertake for proofreading, has many work position step programming function, can achieve more work steps to improve urban disposable machining parts and efficiency.
4 and the selection of ball screw, synchronous belt transmission
Technical parameters of CNC Cutting machine
| Model | Max cutting thickness (mm) | Max cutting width (mm) | Plank material strength m (N/mm2) | Rake angle (°) | No.of strockes (mm/min) | Adi.Distance of back gauge (mm) | Power of main motor (kw) | Over all dimensions (mm) | | 4x2500 | 4 | 2500 | 450 | 1.5 | 22 | 550 | 5.5 | 3020x1490x1590 | | 4x3200 | 4 | 3200 | 450 | 1.5 | 19 | 550 | 5.5 | 3720x1490x1590 | | 4x4000 | 4 | 4000 | 450 | 1.5 | 17 | 550 | 7.5 | 4520x1770x1700 | | 4x6000 | 4 | 6000 | 450 | 1.5 | 10 | 750 | 11 | 6550x2250x2000 | | 6x2500 | 6 | 2500 | 450 | 1.5 | 18 | 550 | 7.5 | 3030x1665x1620 | | 6x3200 | 6 | 3200 | 450 | 1.5 | 15 | 550 | 7.5 | 3730x1665x1620 | | 6x4000 | 6 | 4000 | 450 | 1.5 | 12 | 750 | 7.5 | 4530x1770x1700 | | 6x6000 | 6 | 6000 | 450 | 1.5 | 8 | 750 | 11 | 6580x2400x2100 | | 8x2500 | 8 | 2500 | 450 | 1.5 | 14 | 550 | 7.5 | 3040x1665x1620 | | 8x3200 | 8 | 3200 | 450 | 1.5 | 12 | 550 | 7.5 | 3740x1665x1620 | | 8x4000 | 8 | 4000 | 450 | 1.5 | 10 | 750 | 7.5 | 4530x1770x1700 | | 8x6000 | 8 | 6000 | 450 | 1.5 | 6 | 750 | 18.5 | 6600x2250x2100 | | 10x2000 | 10 | 2000 | 450 | 2 | 13 | 550 | 11 | 2550x1750x1700 | | 10x2500 | 10 | 2500 | 450 | 2 | 11 | 550 | 11 | 3050x1750x1700 | | 10x3200 | 10 | 3200 | 450 | 2 | 10 | 750 | 11 | 3750x1780x1800 | | 10x4000 | 10 | 4000 | 450 | 2 | 9 | 750 | 11 | 4580x1860x2900 | | 10x6000 | 10 | 6000 | 450 | 2 | 6 | 750 | 18.5 | 6650x2100x2300 | | 12x2500 | 12 | 2500 | 450 | 2 | 12 | 750 | 18.5 | 3100x1950x1900 | | 12x3200 | 12 | 3200 | 450 | 2 | 10 | 750 | 18.5 | 3900x2000x1980 | | 12x4000 | 12 | 4000 | 450 | 2 | 8 | 750 | 18.5 | 4600x2100x2100 | | 12x6000 | 12 | 6000 | 450 | 2 | 5 | 750 | 30 | 6700x3045x2600 | | 16x2500 | 16 | 2500 | 450 | 2 | 11 | 750 | 22 | 3150x2120x2000 | | 16x3200 | 16 | 3200 | 450 | 2 | 9 | 750 | 22 | 3950x2120x2000 | | 16x4000 | 16 | 4000 | 450 | 2 | 6 | 750 | 30 | 4650x2200x2100 | | 16x6000 | 16 | 6000 | 450 | 2 | 4 | 750 | 37 | 6850x3100x2700 | | 20x2500 | 20 | 2500 | 450 | 2.5 | 8 | 750 | 30 | 3200x2180x2060 | | 20x3200 | 20 | 3200 | 450 | 2.5 | 7 | 750 | 30 | 4000x2220x2150 | | 20x4000 | 20 | 4000 | 450 | 2.5 | 6 | 750 | 30 | 4680x2300x2200 | | 25x2500 | 25 | 2500 | 450 | 3 | 7 | 750 | 45 | 3220x2280x2130 | | 25x3200 | 25 | 3200 | 450 | 3 | 6 | 750 | 45 | 4020x2330x2220 | | 25x4000 | 25 | 4000 | 450 | 3.5 | 5 | 750 | 45 | 4700x2400x2320 | | 30x2500 | 30 | 2500 | 450 | 3.5 | 6 | 750 | 45 | 3250x2350x2280 | | 30x3200 | 30 | 3200 | 450 | 3.5 | 5 | 750 | 45 | 4050x2450x2360 | | 30x4000 | 30 | 4000 | 450 | 3.5 | 5 | 750 | 45 | 4720x2540x2430 |
|
|
