SPECIFICATIONS
| Basic Functions of Digital Clamp Multimeters | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 400mV/4V/40V/400V/600V | (0.8%+1) |
| AC Voltage | 400mV/4V/40V/400V/600V | (1.2%+5) |
| DC Current | 40A/1000A | (1.5%+8) |
| AC Current | 40A/1000A | (2%+8) |
| Resistance | 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ | (1%+2) |
| Temperature | -40C~1000C | |
| Frequency | 4kHz/40kHz/400kHz/4MHz/40MHz | (1%+3) |
| Duty Cycle | 0.1%~99.9% | |
| Special Functions of Digital Clamp Multimeters | ||
| Auto Ranging | ||
| Diode | ||
| Continuity Buzzer | ||
| True RMS | AC Voltage | |
| Surge Current | AC Current | |
| Peak Max/Peak Min Mode | ||
| Max/Min Mode | ||
| Data Hold | ||
| Sleep Mode | ||
| Display Backlight | ||
| Full Icon Display | ||
| Low Battery Display | ||
| Input Impedance for AC Voltage Measurement | Around 10 M | |
| Max. Display | 4000 | |
| Analogue Bar Graph |
GENERAL CHARACTERISTICS
| Power of Digital Clamp Multimeters | 9V Alkaline Battery (1604A or 6LF22) |
| LCD Size | 47 x 30 mm |
| Product Color | Red and Grey |
| Product Net Weight | 533g |
| Product Size | 285 x 105 x 45 mm |
| Standard Accessories | Test Lead,Alkaline Battery,English Manual,Tool Box |
| Standard Individual Packingt | Gift Box |
| Standard Quantity Per Carton | 5 pcs |
| Standard Carton Measurement | 480 x 372 x 315 (0.056CBM Per Standard Carton) |
| Standard Carton Gross Weight | 11 kg |
*Available at Extra Cost Specifications and other information of Digital Clamp Multimeters are subject to change without further notice. |
