Brand:BFDX
Model:BF-P108
Send Inquiry
1. Noise suppression
2. Better frequency use ratio (6.25KHz)
3. Longer use time of the battery
4. Multi digital codes using for the transceiver
5. Support private call,group call and all call
6. 4 side keys can be programmed
7. High/Low voltage alarm
8. Dual-pin for out microphone and earphone
9. Built-in USB interface
tracy@bfdx.com
www.bfdx.com
Frequency range: VHF:136-174MHz UHF:350-390MHz 400-470 MHz
Channels: 32
Zones: 2
Channel Spacing: 6.25KHz
Working Voltage: DC7.4V(±20％)
BatteryCapacity: 2000mAh (Li-ion battery)
Battery Average Working Time（5/5/90): 17 hours
Frequency Stability: ±1ppm
Antenna Impedance: 50Ω
Dimension: 60*39*103 mm
Weight: 234g (including battery pack)
Transmitting
Power output: H：5W / L: 1W
4FSK modulation: 4K00F1E
Spurious Emission: -36 dBm≤1GHz/-30 dBm≥1GHz
Adjacent Channel Power ≤-60dB
Vocoder: RALCWI
Receiving
Sensitivity: 3%BER≤0.25uV
Audio output power: 500mW
Audio Distortion ＜5%
Conduction Radiation: -57dBm
Environmental Indicators
Operating Temperature: -20℃~+60℃
Storage Temperature: -30℃~+85℃
Damp proof: MIL-STD-810C/D/E/F
Shock&Vibration: MIL-STD-810C/D/E/F
