Model:X120MN12
Product description:
Product Name:X120MN12 wear-resistant steel plate
Quick Details:
| Grade | Mn13 |
| Standard | JIS, AISI, ASTM, GB, DIN, EN |
| Length | as client's request |
| Thickness | 3-50mm |
| Width | 1000-2500mm |
| Place of Origin | Shanghai, China (Mainland) |
| Brand Name | Baosteel |
| Model Number | X120MN12 wear-resistant steel plate |
| Type | Plate |
| Application | construction,bridge,tool,container etc |
| Certification | MTC |
| wear-resistant steel | Mn13 |
X120MN12 wear-resistant steel plate
Standard: GB,ASTM, AISI,JIS,
2. TK:3-50mm
3. Width: 1000-2500 mm
4.Length:4000-8000mm
Detailed Specification
Mn 13 Chemical Composition: C 1.10~1.50 Si 0.30~0.80 Mn 12.00~14.00 S ≤0.050 P≤0.030
Mechanical Properties: tensile strength σb (MPa) ≥637 extensibility δ (%) ≥20 hardness ≤270HB .
heat treatment regime and metallurgical structure heat treatment regime quenching,1060~1100°C,water cooling.
3-5(thickness)mm 1000-1100(mm)Width
6.0-50(thickness)mm1500-2500(mm)Width
Round bar should make according to your request ,Φ20-200(mm) ≤6000(mm)length
features and use scope
High Mn 13 steel sheet,average of initial hardness are 200HBW , shock resistance and wear restistance,have high tensile strength,plastic and toughness and non-Magnetic,though the parts have already frayed very thin,they still can bear of bigger impulsive load of non-broken, they use to the wear-out parts of impact resistance ,such as scaleboard of shot-blasting machine,scaleboard of ball crusher; ball grinder,bucket lip of grab,screw die of crusher and so on .They always use to make simply structure ,the forging which request wear-resistance of low impact,such as scaleboard , pinion rack,the wall of crashing, sleeve and form relieved tooth
Normal specification,3mm,4mm,5mm,6mm 8mm 10mm 12mm 15mm 20mm others need according to your request.
