Dimensions:
? Front Panel: 400 x 124mm
? Diameter of trackball: 38mm

Interface: USB or PS/2

Outstanding Features:
? 65 keys stainless steel top panel mounting keyboard with trackball
? Support OS: Windows 95/98/NT/ME/2000/2003/XP/Vista, Linux and UNIX
? Customized layout available
? Lettering by etching and inking, or laser technology
? Carbon-on-Gold key switch technology (silicon gel)
? Mechanical/ Optical trackball optional
? Waterproof and dustproof
? Very rugged vandal proof design
? Can be cleaned with soapy water, disinfectant or other cleaning agents

Applications:
? Check-in Kiosk, Info-Kiosk, Internet Kiosk, Medical Kiosk, Industrial Control Platform and Gaming Machine.

Material:
? Front Panel: High quality 304# stainless steel
? Keys: High quality 304# stainless steel
? Trackball: High quality 304# stainless steel
? Back panel: Aluminum alloy

Mechanical data:
? Key trip: 1.5mm
? Key pressure: 0.8~1.6 N
? Lifespan: >2 million operations per key
? Gross Weight: 2.0 KGS

Electrical data:
? Input Voltage: 5.0VDC± 5%
? Electric Current: 10mA
? EMC Emission: EN55022
? ESD Standard: Air Discharge 8KV; Contact Discharge 6KV

Environmental Adaptability:
? Operating Temperature: 0° ~+60°
? Storage Temperature: -25° ~+80°
? Relative humidity: 30%~90%
? Atmospheric pressure: 60~106 KPa

Reliability:
? MTBF: >20, 000 hours
? MTTR: < 30 minutes
? CE, FCC, RoHS, ESD compliant
? Waterproof and Dustproof class: IP65 (front panel)
? Vandal resistant class: IK07
