Brand:DELONG
Model:DL-01
1. Packaging : Wooden case;
2. Delivery: 1 day for stock, about 10-15 days for a 20ft container.
3. Packaging Detail：
| Product size (Width*Length) | carton size | N.W. (KGS) |
| 1000mm*1000mm | 1080mm*1080mm*780mm | 1000 |
| 1200mm*1200mm | 1280mm*1280mm*780mm | 1000 |
4. Description:
(1) PTFE molded sheet is manufactured by molding with PTFE granular resin, and then sintering and cooling.
(2) PTFE skived sheet is manufactured by PTFE resin according to the process of pressed shaped, firing and rotary-cut.
5. Specifications:
1) PTFE Skived Sheet specifications:
Thickness: 0.1mm~10mm
Width: 10mm~ 2500mm
Length: According to customer’s request
Operation Temperature: -180℃ ~+260℃
The Monthly output: 100tons
Packing: plastic membrane inside, wooden case outside
2) PTFE Molded Sheet specifications:
Thickness: 3mm~120mm
Width: 1000mmx1000mm, 1200mm*1200mm
Length: According to customer’s request
Operation Temperature: -180℃ ~+260℃
The Monthly output: 600tons
Packing: plastic membrane inside, wooden case outside
6. Feature:
1) Heat resistance property
2) Excellent non-sticky property
3) Good mechanical property with no distortion and low friction coefficient.
4) Excellent insulation property.
4) Being used in sealing the electronic parts.
5) Corrosion resistance.
7. Application:
1) PTFE sheet are used in reaction kettle, storage tank, valve, container, liner and gasket which work under all kinds of corrosive dielectric.
2) It also can be used as liner of anticorrosive pipes. oilless lubricator and abheisve matenal for sliding orbit of machines and dielectric at any frenquencies.
3) Used in wrapping the cables under high voltage and high temperature.
8. Products range: PTFE sheet, PTFE rod, PTFE film, PTFE tube, PTFE parts, etc.
9. Picture:
