Specification

Driving mode

6×4

Engine

Model

Cummins L290 30

Max. power(KW/rpm)

213/2200

Max. torque(N.m/rpm)

1180/1400

Cylinder bore ×Stroke(mm)

114×145

Displacement（ml）

 8900

Type of Fuel

Diesel

Compression ratio

(16.6±0.5):1

Cab

D310-S1

Single berth

Capacity

3 persons

Gearbox

Type

Fast RT-11509G

Max. torque（N.m）

1490

Clutch

Φ430mm

Diaphragm Spring Clutch

 Profile                           Height×Width× Thickness(mm)

300×90×(8+8)

frame width 940 (front ) , frame width 800 ( rear )

No of Spring leaves

 9/10

Tyre

Size

11.00R20

Air conditioner

A/C

Dimensions

Outer dimension (mm)

8200×2500×3200

Inner Dimension (mm)

5400×2500×1500

Wheel base (mm)

3800+1350

Front/Rear tread(mm)

 2040 / 1820

Appr./Depa. angel (°)

30/25

Performance

Max. speed（km/h)

80

Mass

Payload （kg）

15500

Curb weight（kg）

9500

G.V.W （kg）

25000
