Model:sc 150zh
Send Inquiry
| Tricycle ,Cargo tricycle,Three wheeler, Three wheel motorcycle ,Trike | ||
| SC 150ZH Tricycle | ||
| Dimension: | 3300/1380*1400mm | |
| Engine Type: | Single cylinder,4-sroke,spark plug, air cooled | |
| Displacement: | 145.00ml | |
| Max.output(kw/rpm) | 8.2/9000 | |
| Max.torque(kw/rpm) | 9.5/7500 | |
| Cool system | Air cooled, water to option | |
| Ignition: | C.D.I | |
| Bore*Stroke: | 61.0*49.5mm | |
| Weight: | 330 kgs | |
| Compression rate: | 9.2:1 | |
| Starting : | electric/manual | |
| SC 150ZH can assemble 150cc,175cc,200cc ,250cc engine | ||
| The painting | frame is adding the rustless painting | |
| the cargo box can choose two specification, rustless painting and non-rustless painting | ||
| Cargo box | cargo box can depend on your needing , have different size and shape | |
| Battery | have two battery kinds:12V9A , 12V28A | |
| Electrical | ignition system | |
| Drive train | Transmission Primary | |
| frame | Fr.Suspension | Hydraulic pressure |
| Rr.suspension | Hydraulic pressure | |
| frame size | W/L 40/60 | |
| Fr.Tire size | 4.50-12/415 | |
| Rr.Tire size | 4.50-12/415 Have 5.00-12 wheel to option | |
| Fr.Brake | Drum | |
| Rr.Brake | Drum | |
| Fuel tank capacity | 12L | |
| Steel plate | 4+2 steel plate , steel plate outer frame ,which can enhance stabilization | |
| frame dimension: | have three model:40*60/40*80/50*100 | |
| Loading Capacity:55 ( CKD) units in 40 HQ | ||
| Thanks for your time, We would appreciate your inquiry about more details. | ||
