Model: XL150ZH-A
Overall size:3240*1240*1350mm
Shift distance: 2100mm
Wheel distance: 1170mm
Weight: 325kg
Rated loading: 450kgs
Front tire: 3.25-16, steel wheel
Rear tire: 4.50-12/500-12, steel wheel
Engine model: 162FMJ
Bore*Stroke: 62*49.5mm
Displacement: 149.4ml
Maximum Power: 8.5/8500 kw/r/min
Maximum Torque: 9.8/7000Nm/r/min
Transmission: shaft drive
Brake type: F/Drum, R/Drum
32 units/40HQ by SKD
48 units/40HQ by CKD
