Specifications

  1.1000base SFP Transceiver
2.SFP-SX,850nm,VCSEL,550m,MMF
3.Apply with GE/FC
4.Certificated with RoHS/FDA/UL/FCC



Features

*Operating data rate up to 1.25Gbps

*850nm VCSEL Laser Transmitter

*550m with 50/125 µm MMF, 300m on 62.5/125 µm MMF

*Single 3. 3V Power supply and TTL Logic Interface

*Duplex LC Connector Interface

*Hot Pluggable

*Operating Case Temperature

 Standard: 0°C ~+70°C

 Industrial:-40°C ~+85°C

*Compliant with MSA SFP Specification

*Digital diagnostic monitor interface

*Compatible with SFF-8472

Applications

*Gigabit Ethernet

*Fiber channel

*Switch to switch interface

*High speed I/O for file servers

*SonET OC-3 SR1, SDH STM-1, I-1.1
