Capsule：Ø12.5mm-22mm

Number of circuit：4 6 8 12 18, more

Working speed:0-300 rpm

Current Rating：2/5/10amp per circuit

Voltage：240V AC/DC

Temperature Range：-40℃~ +80℃

Operating Humidity: 60%RH or higher

Contact Material: Gold to Gold

Lead Size: 30# silver plated copper Teflon®  UL

Lead Length :Standard250 mm

Housing Material :Engineering plastic or metal

Level of protection：IP54 OR higher

Dielectric Strength：≥500VAC@50Hz Between each circuit

Insulation Resistance: 1000MΩ/500VDC

Work Life：≥60000000rev
