Gr5 Titanium alloy tube
2016-10-26 10:38  Views:88
Price:Negotiable
Model:GB/T3624/GB/T3625 ASTM 337/ASTM338
Send Inquiry

Description

1.Standards:GB/T3624/GB/T3625 ASTM 337/ASTM338


2. Material : GR1 GR2 GR5 GR7 GR9 etc.

3. Size:  OD: 6--300MM ;

                 I D: 4--280MM ;

                Wall Thickness:0.2--4.5mm ;

                L: 100--8000MM

   (according to customer requirements and drawing processing .)


4.Advantage:  Light weight,resistance to acid and alkali, dystectic point High precision ,

     Alloy TC4, TC6, TC11 in between 400 -- 500 degrees          Celsius Does not affect performance.

Titanium table

Production

Name

grade2 grade5 grade7 asme sb 338 titanium tube

Grade

Gr5

Size

8-60*0.5-10*9000mm

Standard

ASTM B338

Application

heat exchanger,condensor .

environmental protection equipment

cooling pipe

titanium heat pipe

Electroplating equipment

ring

precision instruments

Feature

High corrosion resistance,

low density,

good thermal stability

Advantage Light quality, high strength, superior mechanical properties

Ingredient list

Grade N ≤ C ≤  H ≤ Fe ≤ O ≤         Al       V         Pd
Gr1 0.03 0.10 0.015 0.20 0.18
Gr2 0.03 0.10 0.015 0.30 0.25
Gr4 0.05 0.10 0.015 0.50 0.40
Gr5 0.05 0.10 0.015 0.40 0.20   5.5~6.75 3.5~4.5
Gr7 0.03 0.10 0.015 0.30 0.25     0.12~0.25
Gr9 0.02 0.10 0.015 0.25 0.15     2.5~3.5 2.0~3.0

Titanium merits

Titanium ,as the forth abundant element on the earth crust,is now well understood by people for its low density,high strength and excellent corrosion resistance and widely used in many fields,such as chemical industry ,petrochemical industry,used in surgical implants,seawater desalination,ocean environment protection,motor vehicle industry and sports industries.Junde Industry International Group Limited makes affordable.


Titanium tube application

Petrochemical Industry, Ocean environmental protection, Chemical industry, bicycle industry, corrosive environment  motor vehicle industry.
