Model:SL300
Z Rapid SL300 RAPID PROTOTYPING SYSTEM
Specifications
Technology: Stereo lithography, additive layer manufacturing
Material Class: Photo reactiveresin
| LASER SYSTEM | |
| Type | Diode-pumped solid-state laser Nd:YVO4 |
| Wavelength | 354.7nm |
| Power at vat at 5000 hours | 300mW |
| Power auto-adjustment | Optional |
| RECOATING SYSTEM | |
| Process | Intelligent reduced vacuum press recoater |
| Normal build style | 0.1mm |
| Quick build style | 0.125mm |
| Precision build style | 0.075mm |
| OPTICAL & SCANNING | |
| Beam (diameter@1/e2) | 0.10-0.15mm |
| Focus style | ScanLab |
| Part drawing speed | Recommended 6.0m/s |
| Beam jump speed | Recommended 10.0m/s |
| Reference Build Weight | 60 ~ 100g/hr |
| ELEVATOR | |
| Vertical resolution | 0.0005mm |
| Position repeatability | ±0.01mm |
| Maximum part weight | 50kg |
| RESIN VAT | |
| Volume | Approx. 45.0L (50kg) |
| Maximum build box | 300mm(X)×300mm(Y)×200mm(Z) |
| Resin heated style | Hot air |
| SOFTWARE | |
| Operating system | Windows 7, Ethernet, IEEE802.3 |
| Preparation software | Materialise Magics RP (optional) |
| Build software | ZERO 4.0 build software |
| CAD interface | 3D design software, STL file format |
| INSTALLATION ConDITION | |
| Power | 200-240VAC 50/60Hz, single phase, 12Amps |
| Ambient temperature | 20-26oC |
| Built-in air condition | Optional |
| Relative humidity | Less than 40%, non-condensing |
| Size | 1.2m(W)×0.9m(D)×1.75m(H) |
| Weight | Approx.530kg |
| WARRANTY (Terms & conditions apply) | |
| Laser | 5000 hours or 12months (whichever comes first) |
| Main machine | One (1) year from installation date |
